Integral floor structure, Corrosion-resistant steel

Doors

Material

steel door

Specification（mm）

840*2035

Opening method

inward opening/outward opening

Material

plastic steel

Windows

Specification（mm）

500*500 /800*500/ 800*1100 / 1120*1100

Opening method

sliding

Glass

4mm+9A+4mm   Insulating  glass

Accessories

screen window, anti-theft guardrail

Wall Panel

Overall thickness（mm）

50mm/75mm

Color-coated steel thickness（mm）

0.4

Core material and bulk density（kg/m³)

30mm/50mm SPS

Flooring

Material

Cement fiber board + rubber floor

thickness（mm）

30mm

Insulation Course

Roof

50mmPU

Floor

Optional

Roof Drainage

Column-Integrated Drainage System

50 PVC downpipe

Electrical Provisions

Outdoor:

Connector: 2P (grounded) 32A industrial plug

Interior:

2*36W single-tube fluorescent lamps

1*10-position full-plastic lighting box

3*five-hole sockets

1*air conditioner socket

1*single large-button switch
